Metz Connect

METZ CONNECT MMF881A315-0001 wire connector 12 Metallic - METZ

Name: METZ CONNECT MMF881A315-0001 wire connector 12 Metallic - METZ
Brand: Metz Connect

M12 Jack X-coded IP67, field assembly with flange - 8-pole M12 jack for field assembly Cat.6A - per IEC/PAS 61076-2-109 with flange - suitable for 10 GBit as per IEEE 802.3an - AWG 26/1 to 22/1, AWG 26/7 to 22/7 can be connected - solid copper wire diameter 0.4 to 0.64 mm - stranded copper wire diameter 0.48 to 0.76 mm - wire diameter with isolation up to 1.6 mm - overall cable diameter from 5.0 to 9.7 mm - jack consists of only two parts - easy assembly without special tools - industry-compatible zinc die-cast housing - suitable for applications in the railway industry Technical details Insulation resistance: 100 M Housing material: Zinc Wire diameter: 1.6 mm Weight & dimensions Width: 16.8 mm Depth: 49 mm Height: 16.8 mm Operational conditions Operating temperature (T-T): -40 - 85 °C Storage temperature (T-T): -40 - 85 °C Packaging data Package weight: 36 g Package type: Polybag Certificates Compliance certificates: RoHS Features Connector(s): 12 Product colour: Metallic Cable standard: Cat6a Connector contacts plating: Nickel/Gold Connector shielding: Yes International Protection (IP) code: IP67 Voltage: 50/60 V Current: 0.5 A Certification: DIN EN 61076-2-109:2010-08, DIN EN 50155, DIN EN 45545-2Meer tonen

vanaf € 40,32

1 aanbieding

↑ Beste prijs de laatste 30 dagen met 5% gestegen

Bekijk aanbiedingen
